50-300L Automatic Oil&Chemical Liquid Filling Machine-WeighingType 50-300L Automatic Oil&Chemical Liquid Filling Machine-WeighingType

This machine is suitable for oil, chemical liquid, bee honey, fruit concentrate, syrup…ect.
Capacity: 20-100BPH
Bottle volume from 50-300L

Quantity:
Share this:
  • Model: LCJ-300L
  • Brand: LINKS MACHINERY
  • Code: 8422301090
  • Product Description
50-300L Automatic Oil&Chemical Liquid Filling Machine-Weighing Type


The machine controlled by PLC programmable and it has a weighing sense platform. Firstly peel weighing and feedback the information and then filling and weighing. In order to avoid foam appearance due to strong impulsion, this product has diving filling (fast and slow) function. When the filling head is close to bottleneck it can add measure slowly for controlling liquid out of bottle. This  type of machine has two measure specifications, CJ-300B weighing range 50-300kg CJ-50 weighing range 50kg.

No. Model Speed
1 Speed 20-100B/H
2 Measurement Precision ±0.2%
3 Air pressure 0.6-0.8Mpa
4 Total power 0.5kw
5 Weight 180kg


No. Name of parts Producing area
1 Programmed controller MitsubishiJapan
2 Low-pressure breaker Siemens Germany
3 AC electromagnetic contractor Siemens Germany
4 AC electromagnetic contractor Siemens Germany
5 Heat-break device Siemens Germany
6 Multi-continuous electrical device Siemens Germany
7 Middle-continuous electrical device Omron Japan
8 Inducing on-off AUTONICS USA


1) Can your factory provide the whole plant from A to Z?

A: Yes, we can provide the complete plant, from bottling making plant, water purification plant, to filling packing plant.
2) How can I know the machinery quality before I order?

A: Frist, we will invite you visiting our factory to check the machines quality, and show the machines running for you in our factory.

3)What certificates you can provide?

A: Our factory provide the CE, SGS, ISO, and accroding to some countries, we also can provide the Pvoc, Coc, Soncap...ect

4)Can your factory make the bottle drawing, workshop layout, and labels for us?

A: We can help customers design their own bottle shape, workshop layout and label drawings, these jobs are free charge.
(Workshop need customer to provide the size of factory)
5)Installation and Training Time

A: We have professional engineer for oversea installaion and training, they can speak English, and have much experience oversea work.
Customer needs to provide the engineer visa, air tickets, sleep room and meals. Each day salary is 80usd, around 20-40days.

6) Warranty time:

We provide the 18 months as our machinery parts warranty time, and electric parts warranty time is 12 month.
