1. The shape is artistic、excellent, the frame is novel、unique, and repair is easy. 2. Electronic induction feeding film, with stable and smooth transfer speed, replacing film quickly. 3. Using isothermal sealing cuter, the seal intensity is 3 times above cooling and sealing cutter, the seal is even and the life is 80 times above cooling and sealing cutter. 4. 3 sets of frequency control transport system, the transmission is precise and synchrony. 5. Adopting air circulation technology, the shrinkage chamber features rational structure, heat insulation, high precision for temperature control and better packing effects.
Main technical parameters:
Packing form： 2*2, 2*3, 3×4、4×6 （or appointed packing spec ）
Packing speed: 10-12pcs/min
Applicable container shape：circular container、PE bottle、container outer diameter:￠40～￠110，height :60～340mm circular or quadrate container.
Total power charge：19kw/380v
Machine size：L×W×H=5500×3200×2100（mm）
Operating air pressure：0.6～0.8Mpa
Air consumption 0.5stere/min
Conveyor belt extreme breadth：304mm
Conveyor height：according to fills Production line（Adjusting scope 200mm）
Main performance features
1. The shape is artistic、excellent, the frame is novel、unique, and repair is easy.
2. Electronic induction feeding film, with stable and smooth transfer speed, replacing film quickly.
3. Using isothermal sealing cuter, the seal intensity is 3 times above cooling and sealing cutter, the seal is even and the life is 80 times above cooling and sealing cutter.
4. 3 sets of frequency control transport system, the transmission is precise and synchrony.
5. Adopting air circulation technology, the shrinkage chamber features rational structure, heat insulation, high precision for temperature control and better packing effects.
